  Build Your Kitchen System
Other Builders:     BATH BUILDER,   HRV/ERV BUILDER,   TANKLESS WATER HEATER BUILDER

We built the "Kitchen System Builder" to help our customers visualize a typical installation and how different options and fans affect overall system performance. Note that the diagram may not exactly represent your specific system. However, it will show you a standard configuration based on the options you choose. Start by selecting items in each of the 5 categories below. Once you press the "Calculate & Show Fans" button, a list of fans and additional items will be displayed. Choose the fan and options and click the "Add to Basket Button".
Questions? Call us at 877-711-4822.
Start Select EACH Item
1 - Hood Liner Hood Liner
-- AirScape Liners --
AHL-30 = 28.5x22", 8" Duct
AHL-36 = 34.5x22", 8" Duct
AHL-42 = 40.5x22", 10" Duct
AHL-48 = 46.5x22", 12" Duct
-- Fantech Liners --
SGHL 30 = 28.5x18", 6" Duct
SGHL 36 = 34.5x18", 8" Duct
SHL 36 = 34.5x22", 8" Duct
SHL 42 = 40.5x22", 10" Duct
SHL 48 = 46.5x22", 10" Duct
NO HOOD
2 - Backdraft Damper Backdraft Damper
YES NO
3 - Duct Components Duct Length & Elbows
  Approx. Ft. of Duct

  # of Elbows
4 - Silencer Silencer
YES NO
5 - Inline Exhaust Inline Exhaust Fan
IN-LINE FAN WITH ROOF CAP EXHAUST
IN-LINE FAN WITH SIDE WALL EXHAUST
ROOF/SIDE WALL EXHAUST FAN (RE roof unit shown on picture)
5 - Roof Exhaust
    3 - Elbow 4 - Silencer 5 - Exhaust Fan 3 - Elbow Right
  2 - Backdraft Damper
Kitchen
1 - Hoodliner
Kitchen
(Click button above to calculate and display fan options)
